Kingston ValueRAM KVR32N22S8/8 8GB DDR4-3200 CL22 288-Pin DIMM

Kingston ValueRAM KVR32N22S8/8 is an 8 GB DDR4-3200 SDRAM memory module configured as 1Rx8 and designed in a 288-pin DIMM format. The module operates with a JEDEC-programmed DDR4-3200 timing of 22-22-22 at 1.2 V.

Built with eight 1G x 8-bit FBGA components, the module provides a 1G x 64-bit organization and uses gold contact fingers. It is a single-rank ValueRAM module for systems that support compatible 288-pin DDR4 DIMM memory.

Key Features

• 8 GB Capacity: 1G x 64-bit DDR4 SDRAM memory organization.
• DDR4-3200 Speed: PC4-3200 memory with JEDEC-programmed operation.
• CL22 Timing: Programmed to 22-22-22 timing at 1.2 V.
• Single-Rank Design: 1Rx8 configuration using eight 1G x 8-bit FBGA components.
• 288-Pin DIMM: Full-size DIMM module with gold contact fingers.
• Compliance: RoHS compliant and halogen-free.

Technical Specifications

Compatibility & Important Information

• This product is a 288-pin DDR4 DIMM memory module.
• Its SPD is programmed to JEDEC DDR4-3200 timing of 22-22-22 at 1.2 V.
• Before purchase, confirm that the target system specifies compatible 288-pin DDR4 DIMM memory and supports an 8 GB module with the required memory parameters.
