Skullcandy TERRAIN XL Bluetooth Portable Speaker Black [ 2SKSK1848B0L2 ]

Skullcandy Terrain XL Speaker

Skullcandy TERRAIN XL Bluetooth Portable Speaker Black [ 2SKSK1848B0L2 ]

Features

Functions

Power ON / OFF: Press and hold the “O” button for 2s. If not connected to a BT device or connected but idle (not playing audio) speaker will turn OFF automatically after 15 min.

Play / Pause: Press the “►” button once to play or pause audio.

Volume up: Press “+” button to increase the volume.

Volume Down: Press “-” button to decrease the volume.

Next Track: Press and hold “+” button for 2s to skip track.

Previous Track: Press and hold “-” button for 2s to go to last track.

Bluetooth® Pairing: Press and hold BT Button for 3s to enter BT pairing mode. Speaker will disconnect from any paired BT device and be available to pair to new devices. Speaker will stay in pairing mode for 60s, or until connected. Status LED will blink blue while in BT pairing mode.

True Wireless Stereo Pairing: Press “O” button 3 times to pair any two SKDY Terrain speakers to play audio in stereo. Status LED will be blue to indicate Right channel and yellow to indicate Left channel.

Exit True Wireless Stereo Mode: Press “O” button 3 times to exit TWS pairing.

SKDY Multi-linkTM Mode Transmitting: Press and hold the “►” and “+” button together for 1s to set speaker as transmitting. Status LED will be purple.

SKDY Multi-linkTM Mode Receiving: First disconnect speaker from any BT device by single pressing the BT button. Then press and hold the “►” and “+” button together for 1s to set speaker as receiving. Status LED will be green.

Check Battery Status: The 4 LED indicators show the battery level. Press and hold “+” and “-“ buttons together for 1s, for a more accurate battery level indication. A voice prompt will say the battery level.

CHARGING

Use the USB-CTM cable included to connect the speaker to an appropriate power source to begin charging.

The LED indicators will show battery is charging.

When all 4 LEDs are ON the battery is fully charged.

Warning:

1. To avoid damage to the speaker and battery, it is important to only use a power source that matches the power requirements listed on the speaker’s rating label.

2. To avoid overheating, it’s recommended not to place the speaker in direct sunlight, especially while charging and playing music.

Battery status indication (not charging):

0-5% – speaker is OFF all 4 LEDs are OFF

5-10% – 1st LED blinks red, other LEDs are OFF

10-25% – 1st LED is ON white, other LEDs are OFF

25-50% – 1st + 2nd LEDs are ON white, other LEDs are OFF

50-75% – 1st + 2nd + 3rd LEDs are ON white, other LEDs are OFF

75-100% – All LEDs are ON white

Battery status indication (while charging):

0-25% – 1st LED blinks white, other LEDs are OFF

25-50% – 1st LED is ON white, 2nd LED is blinking. Other LEDs are OFF

50-75% – 1st + 2nd LEDs are ON white, 3rd LED is blinking. Other LEDs are OFF

75-99% – 1st + 2nd + 3rd LEDs are ON white, 4th LED is blinking. Other LEDs are OFF

100% – All 4 LEDs are ON white

TROUBLE SHOOTING

Factory Reset:

Press and hold “-” and “+” buttons for 10s to initiate factory reset. The speaker will revert to factory settings and all previously paired devices will be deleted. Status LED will blink alternating between blue and red while resetting.

DUT Mode:

If the speaker is charged but not turning ON, or if it is not functioning properly, it may be in DUT mode. Hold the “O” button for 12s to exit DUT mode and reset the speaker.

Low Battery:

If the speaker’s battery is fully depleted, it may not turn ON immediately even when connected to a power source. Please plug the speaker into an appropriate power source and let it charge for at least 10 minutes before turning it ON.

SPECIFICATIONS

# Bluetooth version: 5.3 ®

# Battery capacity: 7.2V/3350mAh (X2)

# Charging input: DC 5V/2A

# Play time: Up to 10 hours

# Charging time: 3.5-4 hours

# Operating range: 10M

# Rated Power: 20W

# Connection Type: USB-C

# Battery Standby Time: 365 Days

# IPX Rating: IPX7 (water immersion of 1m, for up to 30 min)

What’s in the box:

# Terrain™ XL Bluetooth® Portable Speaker
# 3ft USB-C Charging Cable
# Wrist Strap
# User Guide
