Cudy Outdoor 4G LTE Cat 4 N300 Wi-Fi Router

Model Version:   LT400 Outdoor 1.0

CPU

• Chipset: MT7628
• CPU Details: 580 MHZ Single-Core, MIPS24KEC

Memory/Storage

• Flash/ROM: 8 MB (64 Mbit ) NOR
• DDR/RAM: 64 MB (512 Mbit) DDR2

Cellular

• Cellular Standards: 4G Cat. 4
• Cellular Antennas: 2× Fixed
• Detachable Cellular Antennas Connector: SMA Female
• SIM Options: 1× Nano SIM Slot
• Available Versions: EU, US

EU Version Cellular

• Suitable Region: Europe, Middle East, Africa
• Max DL Speed: 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD)
• Max UL Speed: 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD)
• Advanced: DL 2×2 MIMO
• Cellular Bands: LTE-FDD: B1/3/5/7/8/20/28 , *** LTE-TDD: B38/40/41 ,*** WCDMA: B1/5/8

US Version Cellular

• Suitable Regio:   United States, Canada
• Max DL Speed: 150 Mbps
• Max UL Speed: 50 Mbps
• Advanced: DL 2×2 MIMO
• Cellular Bands: LTE-FDD: B2/4/5/12/13/14/66/71 , ***WCDMA: B2/4/5

Wireless

• 2.4 GHz Wi-Fi Speed: 300 Mbps
• 2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
• Wi-Fi Antennas: 2× Internal
• Beamforming: True
• Range Performance: Max: 170 m (558 ft) , Park: 150 m (492 ft) , Street: 30 m (98 ft)  Woods: 30 m (98 ft)

Interfaces

• Physical Buttons: Reset Button
• 10/100 Mbps RJ45 Ports: 1
• Ethernet Notes: Accepts PoE powering
• LED: System , Internet , LAN , Wi-Fi , Cellular Signal Strength
• Power Input: PoE via Ethernet Port

Power

• Power Methods : Passive PoE
• Passive PoE: 24V
• Power Adapter: Input: 100 ~ 240 V, 50/60 Hz AC , Output: 24V 0.5A DC
• Max Power Consumption (W): 8W
• Idle Power Consumption (W): 4W

Reliability

• Lightning/Surge Protection: DM 2kV, CM 4kV
• ESD Contact Protection: 4kV
• ESD Air Protection: 8kV

Environment

• Operating Temperature: -20 ℃ ~ 60 ℃ (-4 ℉ ~140 ℉)
• Extend Operating Temperature with Industrial Grade SIM Card: -40 ℃ ~ 65 ℃ (-40 ℉ ~ 149 ℉)
• Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
• Operating Humidity: 0% ~ 100% non-condensing
• Storage Humidity: 5% ~ 90% non-condensing
