16-Port 10/100 Long Range PoE+ Surveillance Switch

Description

The D-Link DES-F1016P-E is a 16-port Fast Ethernet PoE+ switch designed for surveillance and network expansion. It features 16 PoE-enabled ports and 1 Gigabit Combo (RJ45/SFP) uplink port, supporting a total PoE power budget of 150W. With a maximum transmission distance of 250 meters, it's ideal for powering devices like IP cameras and access points over extended distances.

Key Features:

• 16 x 10/100 Mbps PoE ports

• 1 x Gigabit Combo (RJ45/SFP) uplink port

• Supports IEEE 802.3af/at PoE standards

• Total PoE power budget of 150W

• Maximum transmission distance of 250 meters

• Plug-and-play installation with no configuration required

• IEEE 802.3x Flow Control for reliable data transmission

• Auto MDI/MDIX crossover for all ports

• Fanless design for silent operation

Specifications:

• Dimensions: 285 x 180 x 44 mm

• Weight: 2.1 kg

• Material: Metal housing

• Color Options: Black

• Power Requirements: 100–240 V AC, 50/60 Hz

• Other Specs:

  • Switching Capacity: 5.2 Gbps

  • Packet Forwarding Rate: 3.868 Mpps

  • MAC Address Table: 8K entries

  • Packet Buffer Memory: Not specified

  • Operating Temperature: 0°C to 40°C

  • Storage Temperature: -20°C to 70°C

  • Humidity: Operating: 10% to 90% non-condensing; Storage: 5% to 95% non-condensing

  • Certifications: CE, FCC, RoHS
